30
XYZ
| Availability: | |
|---|---|
| Quantity: | |
| Max. working speed | 30 packs/min |
| Packing range | L(120~500)/W(110~420)/H(40~110)mm (excluding the handle length) |
| Scope of application | Single soft pack facial tissue, bundle packing |
| Bundle packing style (layer * Row * Column) | 1*1*(3~5) 1*2*(3~5) |
| Design working speed | 30 bags/min |
| Stable working speed | ≤ 30 bags/min(relate to packaging specification) |
| Bag storage structure | Dual bag racks |
| Bag storage quantity | ≤ 400 bags |
| Single pack facial tissue range | L110~180mm*W90~110mm*H40~100mm |
| Packaging film material | CPP/PE film,thickness 0.05mm |
| Machine dimension | L3060*W2200*H1710 |
| Machine weight | 1800KG |
| Total power | 17KW |
| Air compression | Pressure≥0.6 MPA, Flow≥300L/min(buyer prepares) |
| Machine movement control mode | 10 axis servo axis positioning control |
| Gusset forming mode | Vacuum mold forming |
