| Max. working speed | 350 cuts/min |
| Cutting range | L(90~210)/W(80~110)/H(25~100) |
Control system
| PLC and sservo control, touch screen operation |
| Feeding mode | Servos drive, timing belt for conveying |
| Cutting mode | 360 rotation cutting° |
| Log begin and end cutting system | PLC control, touch screen setting,15~25 mm |
| Cutting precision | Tolerance < 1mm |
| Granding system | Auto granding, touch screen setting |
| Circle blade dia | Φ610 mm (min.400mm) |
| Air compression | 0.5 mpa(buyer prepares) |
| Power supply | 380V/50HZ |
| Total power | 10KW |
Machine dimension
| L1500*W1500*H1700mm |
| Machine weight | 1500KG |
